Mobile Control Quick Charging Equipment for Electric Vehicles

The utility model discloses a mobile control electric vehicle quick charging device, which is characterized in that it comprises an energy storage unit, which provides electric vehicle charging electric energy with the external power grid. The energy storage unit comprises a battery energy storage group and an energy storage battery controller. The energy storage unit is connected with the distribution current debugging unit; The fast charger is connected with the distribution current debugging unit, the fast charger is connected with the charging control circuit, the charging control circuit is provided with a data transceiver unit connected to the mobile phone terminal, the mobile phone terminal to achieve charging, electricity charging multi-functional control. The device adopts efficient, fast, intelligent and fast design positioning highly fit the quick charging demand of the car, and adopts human-machine interaction mode to achieve fast charging, mobile control, simple and convenient operation process, and higher charging efficiency.

Sovereignty items: 1. The mobile control electric vehicle quick charging equipment, which is characterized in that it includes: energy storage unit, with the external power grid to provide electric vehicle charging energy, the energy storage unit includes battery energy storage group, energy storage battery controller; The energy storage unit is connected with the distribution current debugging unit; The fast charger is connected with the distribution current debugging unit, the fast charger is connected with the charging control circuit, the charging control circuit is provided with a data transceiver unit connected to the mobile phone terminal, the mobile phone terminal to achieve charging, electricity charging multi-functional control.
